Jona Outdoor Series LED
Introducing the Jona Series LED Video Wall Displays, engineered to deliver powerful visual performance for events, concerts, and professional staging environments. Designed as a rental-focused LED display solution, it offers high brightness, sharp image quality, and vibrant color accuracy that captivate audiences in both indoor and outdoor settings. Built with durable mechanical construction, this LED video wall is ideal for frequent installation and dismantling, making it a reliable choice for event production companies and live shows.
Equipped with advanced three-layer waterproof protection, the Jona Series ensures stable performance in challenging conditions. It supports full front and rear maintenance, while lightweight LED cabinets and magnetically attached modules allow easy, single-person handling. With a quick-lock system, seamless panel alignment, and signal backup support, this LED display guarantees efficiency, safety, and uninterrupted performance for rental LED screens, stage backdrops, and digital event displays.
- High brightness LED display for clear visibility
- Three-layer waterproof outdoor LED protection
- Lightweight rental LED cabinets for easy handling
- Quick-lock system for fast installation
- Signal backup port for uninterrupted performance
- Ideal for events, concerts, and stage LED video walls
| Parameter Model | Outdoor P3.6 | Outdoor P4.8 |
|---|---|---|
| LED Lamp | SMD1820 | SMD1820 |
| Pixel Pitch | 3.6mm | 4.8mm |
| Pixel Density | 77,160 pixels/m² | 43,402 pixels/m² |
| Pixels Per Panel | 25,600 pixels | 14,400 pixels |
| Module Size | 288mm*288mm | 288mm*288mm |
| Module Resolution | 80*80 dots | 60*60 dots |
| 60*60 dots | 576mm*576mm | 576mm*576mm |
| Panel Resolution | 160*160 dots | 120*120 dots |
| Panel Weight | 9 Kgs | 9 Kgs |
| Module Maintenance | Front/Rear | Front/Rear |
| Curve | (Convex) -6°,-3°,0°,+3°,+6°(Concave) | (Convex) -6°,-3°,0°,+3°,+6°(Concave) |
| Brightness | 4000 Nits | 4500 Nits |
| Aspect Ratio | 1:1 | 1:1 |
| Panel Area | 0.331776 ㎡ | 0.331776 ㎡ |
| Recommended Viewing Distance | ≥3.6M | ≥4.8M |
| Environment | ≥3.6M | ≥4.8M |
| Environment | Outdoor | Outdoor |
| Protection level | IP65 | IP65 |
| Material | Die-cast Aluminum | Die-cast Aluminum |
| Control unit | Nova Star | Nova Star |
| Brightness Control | Software/Automatic | Software/Automatic |
| Color Temperature | 7500 K | 7500 K |
| Viewing Angle | Horizontal≥140°,Vertical ≥120° | Horizontal≥140°,Vertical ≥120° |
| Contrast Ratio | 8,000:1 | 8,000:1 |
| Input Power (Max) | ≤200W/pc | ≤200W/pc |
| Input Power (Typical) | 150W/pc | 150W/pc |
| Input Voltage | 220V | 220V |
| Scan Method | 1/20 | 1/10 |
| Refresh Rate | 3840@60 Hz | 3840@60 Hz |
| Video Frame Rate | 50/60 Hz | 50/60 Hz |
| Input Power Frequency | 50~60 Hz | 50~60 Hz |
| Mean fault free | ≥10,000 Hours | ≥10,000 Hours |
| LED Life Time | 100,000 Hours | 100,000 Hours |
| Operating Temperature | -10℃~+45℃ | -10℃~+45℃/td> |
| Operating Humidity | 10-80% No Condensation | 10-80% No Condensation |
| Standard Mounting Configuration | Standard Mounting Configuration | Hanging, Stacking |
LED displays are revolutionizing the way businesses operate and sold in today’s dynamic landscape
Designed to withstand rain, dust, and harsh outdoor conditions, ensuring reliable performance and protection in all weather environments without affecting display quality.
Uses certified Kinglight LEDs that provide stable brightness, accurate colors, and long-lasting performance, making them suitable for continuous outdoor display usage.
Delivers high brightness levels for clear visibility even under direct sunlight, ensuring content remains sharp and readable in bright outdoor conditions.
Strong die-cast cabinet design offers durability, precise panel alignment, and better heat control, making it ideal for long-term outdoor installations.
Built-in signal backup system ensures continuous display operation even during signal failure, preventing screen blackout during critical outdoor usage.
Advanced 4-layer PCB improves heat management, enhances stability, and supports consistent performance during long operating hours in outdoor environments.
Fast-rigging design allows quick installation and dismantling, saving time and effort during outdoor events, rentals, or temporary display setups.
Universal hub system simplifies connections and maintenance, allowing quick module replacement and reducing downtime during servicing or outdoor operation.
